User’s Manual of WGSD-10020 Series
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.12.9 DHCP Snooping Statistics
This page provides statistics for DHCP snooping. The statistics only counter packet under DHCP snooping mode is enabled and
relay mode is disabled. And it doesn't count the DHCP packets for system DHCP client. The DHCP Snooping Port Statistics
screen in Figure 4-12-9 appears.
Figure 4-12-9 DHCP Snooping Port Statistics screen page screenshot
The page includes the following fields:
Object Description
• Rx and Tx Discover
The number of discover (option 53 with value 1) packets received and
transmitted.
• Rx and Tx Offer
The number of offer (option 53 with value 2) packets received and transmitted.
• Rx and Tx Request
The number of request (option 53 with value 3) packets received and transmitted.
• Rx and Tx Decline
The number of decline (option 53 with value 4) packets received and transmitted.
• Rx and Tx ACK
The number of ACK (option 53 with value 5) packets received and transmitted.
• Rx and Tx NAK
The number of NAK (option 53 with value 6) packets received and transmitted.
