User’s Manual of WGSD-10020 Series
range 1-4095 or 'Any'
• Confict
Displays QCE status. It may happen that resources required to add a QCE may
not available, in that case it shows conflict status as 'Yes', otherwise it is always
'No'.Please note that conflict can be resolved by releaseing the resource required
by the QCE and pressing 'Refresh' button.
• Action
Indicates the classification action taken on ingress frame if parameters
configured are matched with the frame's content.
There are three action fields: Class, DPL and DSCP.
Class: Classified QoS Class; if a frame matches the QCE it will be put in the
queue.
DPL: Drop Precedence Level; if a frame matches the QCE then DP level will set
to value displayed under DPL column.
DSCP: If a frame matches the QCE then DSCP will be classified with the value
displayed under DSCP column.
• Modification Buttons
You can modify each QCE in the table using the following buttons:
: Inserts a new QCE before the current row.
: Edits the QCE.
: Moves the QCE up the list.
: Moves the QCE down the list.
: Deletes the QCE.
: The lowest plus sign adds a new entry at the bottom of the list of QCL.
Buttons
: Click to refresh the page. This will help to check the latest conflict status after releasing the resources.
4.9.11.1 QoS Control Entry Configuration
The QCE Configuration screen in Figure 4-9-14 appears.
