User’s Manual of WGSD-10020 Series
519
mld : IPMC for IPv6 MLD
igmp: IPMC for IPv4 IGMP
<vid> : VLAN ID (1-4095) or 'any', default: Show all VLANs
<port_list>: Port list or 'all', default: All ports
Example:
Show VLAN 1 & port 1-10 SSM related information for IPMC.
WGSD
-10020HP:/>ipmcssm igmp 1 1-10
IPMC Parameter RV
Description:
Set or show the IPMC Robustness Variable.
Syntax:
IPMC Parameter RV [mld|igmp] [<vid>] [ipmc_param_rv]
Parameters:
mld|igmp :
mld : IPMC for IPv6 MLD
igmp: IPMC for IPv4 IGMP
<vid> : VLAN ID (1-4095) or 'any', default: Show all VLANs
ipmc_param_rv:
-1 : Default Value (2)
1~255 : Robustness Variable
(default: Show IPMC Interface Robustness Variable
IPMC Parameter QI
Description:
Set or show the IPMC Query Interval.
Syntax:
IPMC Parameter QI [mld|igmp] [<vid>] [ipmc_param_qi]
Parameters:
mld|igmp :
mld : IPMC for IPv6 MLD
