User’s Manual of WGSD-10020 Series
The page includes the following fields:
Object Description
• Temperature settings
for priority groups
The temperature at which the ports with the corresponding priority will be turned
off. Temperatures between 0 and 255 C are supported.
• Port priorities
The priority the port belongs to. 4 priorities are supported.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.2.17 Web Firmware Upgrade
This page facilitates an update of the firmware controlling the switch. The Web Firmware Upgrade screen in Figure 4-2-20
appears.
Figure 4-2-20 Web Firmware Upgrade page screenshot
To open Firmware Upgrade screen perform the folling:
1. Click System -> Web Firmware Upgrade.
2. The Firmware Upgrade screen is displayed as in Figure 4-2-20.
3. Click the “
“button of the main page, the system would pop up the file selection menu to choose firmware.
4. Select on the firmware then click “
”, the Software Upload Progress would show the file upload status.
5. Once the software be loaded to the system successfully. The following screen appears. The system will load the new
software after reboot.
