User’s Manual of WGSD-10020 Series
168
Figure 4-8-13 MLD Snooping Port Group Filtering Configuration page screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Port
The logical port for the settings.
• Filtering Group
The IP Multicast Group that will be filtered.
Buttons
: Click to add a new entry to the Group Filtering table.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.8.11 MLD Snooping Status
This page provides MLD Snooping status. The IGMP Snooping Status screen in Figure 4-8-14 appears.
