User’s Manual of WGSD-10020 Series
Figure 4-12-1 Port Limit Control Configuration Overview page screenshot
The page includes the following fields:
System Configuration
Object Description
• Mode
Indicates if Limit Control is globally enabled or disabled on the switchstack. If
globally disabled, other modules may still use the underlying functionality, but
limit checks and corresponding actions are disabled.
• Aging Enabled
If checked, secured MAC addresses are subject to aging as discussed under
Aging Period.
• Aging Period
If Aging Enabled is checked, then the aging period is controlled with this input. If
other modules are using the underlying port security for securing MAC
addresses, they may have other requirements to the aging period. The
underlying port security will use the shorter requested aging period of all modules
that use the functionality.
The Aging Period can be set to a number between 10 and 10,000,000 seconds.
