1.5 Product Specification
Product WGSD-10020 WGSD-10020HP
Hardware Specification
Copper Ports 8 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
2 1000Base-SX/LX/BX SFP interfaces (Port-9 and Port-10)
Compatible with 100Base-FX SFP
Console Port 1 x RS-232 DB9 serial port (115200, 8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 20Gbps / non-blocking
Address Table 8K entries, automatic source address learning and ageing
Share data Buffer 1392 kilobytes
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame 9Kbytes
Reset Button
< 5 seconds: System reboot
> 5 seconds: Factory Default
Dimension (W x D x H)
330 x 155 x 43.5 mm, 1U high
Weight
1.4kg 1.8kg
LED
Power,
Link/Act and speed per Gigabit port
Power, FAN Alert,
Link/Act per Gigabit port,
PoE In-Use for port-1~ 8
Power Consumption
Max. 12.8 watts /
43.65 BTU
Max. 172.9 watts /
589.6 BTU
Power Requirement – AC
AC 100~240V, 50/60Hz
Power over Ethernet
PoE Standard
-
IEEE 802.3af / at PoE / PSE
PoE Power Supply Type
-
End-Span
PoE Power Output -
Port-1 to Port-9 per port up to 30.8 watts
(56V DC, 590mA max.)
Maximun total current < 2.68A
Power Pin Assignment
-
1/2(+), 3/6(-)
PoE Power Budget
-
150 Watts
PoE Ability
Number of PD @
7Watts
- 8
Number of PD @
15.4Watts
- 8
Number of PD @
30.8Watts
- 4
