User’s Manual of WGSD-10020 Series
27
Layer 2 Function
Basic Management Interfaces Console, Telnet, Web Browser, SNMPv1, v2c
Secure Management Interface SSH, SSL, SNMP v3
Port configuration
Port disable/enable.
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection.
Flow Control disable / enable.
Bandwidth control on each port.
Power saving mode control
Port Status
Display each port’s speed duplex mode, link status, Flow control status.
Auto negotiation status, trunk status.
Port Mirroring
TX / RX / Both
Many to 1 monitor
VLAN
802.1Q Tagged Based VLAN ,up to 256 VLAN groups
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
Up to 256 VLAN groups, out of 4096 VLAN IDs
Link Aggregation
IEEE 802.3ad LACP / Static Trunk
Support 5 groups of 10-Port trunk support
QoS
Traffic classification based, Strict priority and WRR
8-level priority for switching
- Port Number
- 802.1p priority
- 802.1Q VLAN tag
- DSCP/TOS field in IP Packet
IGMP Snooping
IGMP (v1/v2/v3) Snooping, up to 255 multicast Groups
IGMP Querier mode support
MLD Snooping
MLD (v1/v2) Snooping, up to 255 multicast Groups
MLD Querier mode support
Access Control List
IP-Based ACL / MAC-Based ACL
Up to 123 entries
Bandwidth Control
Per port bandwidth control
Ingress: 500Kb~80Mbps
Egress: 64Kb~80Mbps
SNMP MIBs
RFC-1213 MIB-II
IF-MIB
