User’s Manual of WGSD-10020 Series
4.4.3 Port Thermal Protection Status
This page allows the user to inspect status information related to thermal protection. The Port Thermal Protection Status screen
in Figure 4-4-3 appears.
Figure 4-4-3 Thermal Protection Status page screenshot
The displayed counters are:
Object Description
• Port
The logical port for the settings contained in the same row.
• Temperature
The current temperature for logical port
Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
4.4.4 Port Statistics Detail
This page provides detailed traffic statistics for a specific switch port. Use the port select box to select which switch port details
to display. The selected port belong to the currently selected stack unit, as reflected by the page header. The displayed counters
are the totals for receive and transmit, the size counters for receive and transmit, and the error counters for receive and transmit.
The Port Statistics Detail screen in Figure 4-4-4 appears.
