User’s Manual of WGSD-10020 Series
465
6.14 Power over Ethernet Command
PoE Configuration
Description:
Show PoE configuration.
Syntax:
PoE Configuration
Example:
Show PoE configuration.
WGSD
-10020HP:/>poe configuration
Port Mode
AF/AT Mode Priority Max.Power[W] PowerAlloc[W]
----
------- ---------- -------- --------------- -------------
1 Enabled
802.3at High 30.8 30.8
2 Enabled
802.3at High 30.8 30.8
3 Enabled
802.3at High 30.8 30.8
4
Enabled 802.3at High 30.8 30.8
5 Enabled
802.3at High 30.8 30.8
6 Enabled
802.3at High 30.8 30.8
7 Enabled
802.3at High 30.8 30.8
8 Enabled
802.3at High 30.8 30.8
9 Disabled
802.3at Low 0.0 0.0
10 Disabled
802.3at Low 0.0 0.0
Power management mode
----------------------
Power management mode : consumption
PoE Mode
Description:
Set or show the PoE mode.
Syntax:
PoE Mode [<port_list>] [enable|disable]
