User’s Manual of WGSD-10020 Series
522
6.25 VLAN Control List Command
VCL MAC-based VLAN Configuration
Description:
Show VCL MAC-based VLAN configuration.
Syntax:
VCL Macvlan Configuration
VCL MAC-based VLAN Add
Description:
Add or modify VCL MAC-based VLAN entry.
Syntax:
VCL Macvlan Add <mac_addr> <vid> [<port_list>]
Parameters:
<mac_addr> : MAC address (xx-xx-xx-xx-xx-xx)
<vid> : VLAN ID (1-4095)
<port_list>: Port list or 'all', default: All ports
Example:
Add 00-11-22-33-44-55-66 in VLAN 20 for all port
WGSD
-10020HP:/>vcl macvlan add 00-11-22-33-44-55-66 20 1-10
VCL MAC-based VLAN Delete
Description:
Delete VCL MAC-based VLAN entry.
Syntax:
VCL Macvlan Del <mac_addr>
Parameters:
<mac_addr> : MAC address (xx-xx-xx-xx-xx-xx)
