User’s Manual of WGSD-10020 Series
271
• Rx and Tx Release
The number of release (option 53 with value 7) packets received and transmitted.
• Rx and Tx Inform
The number of inform (option 53 with value 8) packets received and transmitted.
• Rx and Tx Lease Query
The number of lease query (option 53 with value 10) packets received and
transmitted.
• Rx and Tx Lease
Unassigned
The number of lease unassigned (option 53 with value 11) packets received and
transmitted.
• Rx and Tx Lease
Unknown
The number of lease unknown (option 53 with value 12) packets received and
transmitted.
• Rx and Tx Lease
Active
The number of lease active (option 53 with value 13) packets received and
transmitted.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page immediately.
: Clears the counters for the selected port.
4.12.10 IP Source Guard Configuration
IP Source Guard is a secure feature used to restrict IP traffic on DHCP snooping untrusted ports by filtering traffic based on the
DHCP Snooping Table or manually configured IP Source Bindings. It helps prevent IP spoofing attacks when a host tries to
spoof and use the IP address of another host. This page provides IP Source Guard related configuration. The IP Source Guard
Configuration screen in Figure 4-12-10 appears.
