User’s Manual of WGSD-10020 Series
Figure 4-12-10 IP Source Guard Configuration screen page screenshot
The page includes the following fields:
Object Description
• Mode of IP Source
Guard Configuration
Enable the Global IP Source Guard or disable the Global IP Source Guard. All
configured ACEs will be lost when the mode is enabled.
• Port Mode
Configuration
Specify IP Source Guard is enabled on which ports. Only when both Global Mode
and Port Mode on a given port are enabled, IP Source Guard is enabled on this
given port.
• Max Dynamic Clients
Specify the maximum number of dynamic clients can be learned on given ports.
This value can be 0, 1, 2 and unlimited. If the port mode is enabled and the value
of max dynamic client is equal 0, it means only allow the IP packets forwarding
that are matched in static entries on the specific port.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
