User’s Manual of WGSD-10020 Series
16-bit groups of contiguous zeros; but it can only appear once. It also used a
following legally IPv4 address. For example, '::192.1.2.34'.
Provide the IPv6 SNTP Server address of this switch. IPv6 address is in 128-bit
records represented as eight fields of up to four hexadecimal digits with a colon
separates each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::' is
a special syntax that can be used as a shorthand way of representing multiple
16-bit groups of contiguous zeros; but it can only appear once. It also used a
following legally IPv4 address. For example, '::192.1.2.34'.
• VLAN ID
Provide the managed VLAN ID. The allowed range is 1 through 4095
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.2.4 Users Configuration
This page provides an overview of the current users. Currently the only way to login as another user on the web server is to
close and reopen the browser. After setup completed, please press “Save” button to take effect. Please login web interface with
new user name and password, the screen in Figure 4-2-4 appears.
Figure 4-2-4 Users Configuration page screenshot
The page includes the following fields:
Object Description
• Username
The name identifying the user. This is also a link to Add/Edit User.
• Privilege Level
The privilgeg level for the user.
Buttons
: Click to add a new user.
