User’s Manual of WGSW-28040 / 28040P
129
4.7.3 IGMP VLAN Setting
This page provides IGMP VLAN Setting. The IGMP VLAN Setting screen in Figure 4-7-7 & Figure 4-7-8 appears.
Figure 4-7-7 IGMP VLAN Setting page screenshot
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID for this drop down list.
• Snooping State
Enable or disable the snooping state. The default value is "Disabled".
• Querier State
Enable or disable the querier state. The default value is "Disabled".
Buttons
: Click to apply changes.
Figure 4-7-8 IGMP VLAN Status page screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID.
• Snooping State
Display the current snooping state.
• Querier State
Display the current querier state.
• Querier Status
Display the current querier stauts.
• Querier IP
Display the current querier IP.
