User’s Manual of WGSW-28040 / 28040P
132
îš„ 802.1p-based Priority
Configuration 802.1p-based priority
îš„ DSCP-based Priority
Configuration DSCP-based priority
îš„ Priority to Queue Mapping
Configuration priority to queue mapping
îš„ Packet Scheduling
Configuration packet scheduling
îš„ Queue Weught Setting
Configuration queue weight setting
îš„ QoS Remarking Status
Configuration QoS remarking stauts
îš„ QoS Remarking Table
Configuration QoS remarking table
4.8.2 Port-based Priority
This page provides Port-based Priority. The Port-based Priority screen in Figure 4-8-1 & Figure 4-8-2 appears.
Figure 4-8-1 Port-based Priority page screenshot
The page includes the following fields:
Object Description
• Port
Select port for this drop down list.
• Priority (0-7)
Select priority for this drop down list.
Buttons
: Click to apply changes.
