User’s Manual of WGSW-28040 / 28040P
143
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• 802.1p Priority
Remarking
Display the current 802.1p priority remarking.
• DSCP Remarking
Display the current DSCP remarking.
4.8.9 Queue Remarking Table
This page provides Queue Remarking Table. The Queue Remarking Status screen in Figure 4-8-15 & Figure 4-8-16 appears.
Figure 4-8-15 Queue Remarking Table Setting page screenshot
The page includes the following fields:
Object Description
• Priority
Select port for this drop down list.
• New 802.1p Priority
(0-7)
Select new 802.1p priority for this drop down list.
• New DSCP Value (0-63)
Select new DSCP value for this drop down list.
Buttons
: Click to apply changes.
