User’s Manual of WGSW-28040 / 28040P
156
4.9.4.3 802.1X Port Setting
This page allows you to configure the IEEE 802.1X Port Setting. The 802.1X Port Setting screen in Figure 4-9-11 & Figure
4-9-12 appears.
Figure 4-9-11 802.1X Port Setting page screenshot
The page includes the following fields:
Object Description
• Port
Select port for this drop down list.
• Mode
If NAS is globally enabled, this selection controls the port's authentication mode.
The
following modes are available:
Force Authorized
In this mode, the switch will send one EAPOL Success frame when the port link
comes up, and any client on the port will be allowed network access without
authentication.
Force Unauthorized
In this mode, the switch will send one EAPOL Failure frame when the port link
comes up, and any client on the port will be disallowed network access.
Buttons
: Click to apply changes.
