User’s Manual of WGSW-28040 / 28040P
94
4.5.5.2 SVLAN Member Setting
The SVLAN Member Setting screen in Figure 4-5-7 & Figure 4-5-8 appears.
Figure 4-5-7 Add SVLAN page screenshot
The page includes the following fields:
Object Description
• SVLAN ID
Allow assign SVLAN ID for selected port. The range for the SVLAN ID is 1-4094.
• Member Port
Select port number for this drop down list to assign SVLAN ID.
The port must be a member of the same VLAN as the Port VLAN ID.
Buttons
: Click to add new SVLAN.
Figure 4-5-8 SVLAN Status page screenshot
