4.10.4 ACL Policy Setting
This page allows you to configure the ACL Policy Setting. The ACL Policy Setting screen in Figure 4-10-6 appears.
Figure 4-10-6 ACL Policy Setting page screenshot
The page includes the following fields:
Object Description
• Policy Index
Select port for this drop down list.
• VLAN ID (1-4094)
Specifies the ToS value.
• Port Number
Specifies the ToS value.
• Action
Assign the ACL policy rule.
Buttons
: Click to apply changes.
