User’s Manual of WGSW-28040 / 28040P
16
the wall, ceiling or any unreachable place. A wire carries both data and power lowering the installation costs, simplifying the
installation effort and eliminating the need for electricians or extension cords.
Flexibility and Extension Solution
The four mini-GBIC slots built in the WGSW-28040 series are compatible with 1000Base-SX/LX and WDM SFP (Small Form
Factor Pluggable) fiber-optic modules. The distance can be extended from 550 meters (Multi-Mode fiber) up to above
10/20/30/40/50/70/120 kilometers (Single-Mode fiber or WDM fiber). It is well suited for applications within the enterprise data
centers and distributions.
1.3 How to Use This Manual
This User Manual is structured as follows:
Section 2, INSTALLATION
The section explains the functions of the Switch and how to physically install the Managed Switch.
Section 3, SWITCH MANAGEMENT
The section contains the information about the software function of the Managed Switch.
Section 4, WEB CONFIGURATION
The section explains how to manage the Managed Switch by Web interface.
Section 5, COMMAND LINE INTERFACE
The section describes how to use the Command Line interface (CLI).
Section 6, CLI CONFIGURATION
The section explains how to manage the Managed Switch by Command Line interface.
Section 7, SWITCH OPERATION
The chapter explains how to does the switch operation of the Managed Switch.
Section 8, TROUBSHOOTING
The chapter explains how to trouble shooting of the Managed Switch.
Appendix A
The section contains cable information of the Managed Switch.
1.4 Product Features
¾ Physical Port
WGSW-28040
îš„ 28-Port 10/100/1000Base-T Gigabit RJ-45 copper
îš„ 4 1000Base-X mini-GBIC/SFP slots, shared with Port-25 to Port-28
îš„ RS-232 DB9 console interface for Switch basic management and setup
WGSW-28040P
îš„ 28-Port 10/100/1000Base-T Gigabit RJ-45 copper with 24-Port IEEE 802.3af PoE Injector
