¾ Power over Ethernet (WGSW-28040P Only)
■ Complies with IEEE 802.3af Power over Ethernet End-Span PSE
■ Up to 24 ports for IEEE 802.3af / at devices powered
■ Support PoE Power up to 15.4 watts for each PoE ports
■ Auto detect powered device (PD)
■ Circuit protection prevent power interference between ports
■ Remote power feeding up to 100m
■ PoE Management
■ Per port PoE function enable/disable
1.5 Product Specification
Product WGSW-28040 WGSW-28040P
Hardware Specification
Copper Ports
28 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
4 1000Base-X SFP interfaces, shared with Port-25 to Port-28
Switch Processing Scheme
Store-and-Forward
Switch Fabric
56Gbps / non-blocking
Throughput @ 64Kbytes
41.67Mpps
MAC Address Table
16K entries
Share Data Buffer
448K bytes
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame
9216 Bytes
LED
PWR, SYS, LNK/ACT, 1000
PWR, SYS, LNK/ACT, PoE In-Use, 1000,
PWR Alert, FAN 1 & 2 Alert
Dimension (W x D x H)
440 x 200 x 44.5 mm, 1U height 440 x 300 x 44.5 mm, 1U height
Weight
2.7kg 3.9kg
Power Consumption
Max. 12 Watts / 40.92 BTU Max. 202 Watts / 688.82 BTU
Power Requirement
AC 100~240V, 50/60Hz
ESD Protection
6KV DC
Power over Ethernet
PoE Standard - IEEE 802.3af PoE / PSE
PoE Power Supply Type - End-Span
PoE Power Output -
Per Port 48V DC.
Max. 15.4 watts
Power Pin Assignment - 1/2(+), 3/6(-)
PoE Power Budget - 180 Watts

Planet WGSW-28040 Specifications

General

Brand	Planet
Model	WGSW-28040
Category	Switch
Language	English
