4.3.6 Jumbo Frame
This page provides to select the maximum frame size allowed for the switch port. The Jumbo Frame screen in Figure 4-3-11 &
Figure 4-3-12 appears.
Figure 4-3-11 Jumbo Frame Setting page screenshot
The page includes the following fields:
Object Description
• Jumbo Frame (Bytes)
Select any available maximum frame size for the switch. Possible frame size are:
1522 Bytes
1539 Bytes
1552 Bytes
9216 Bytes
Buttons
: Click to apply changes.
Figure 4-3-12 Jumbo Frame Information page screenshot
The page includes the following fields:
Object Description
• Jumbo
Display the current maximum frame size.
