User’s Manual of WGSW-28040 / 28040P
95
The page includes the following fields:
Object Description
• SVLAN ID
Display the current SVLAN ID entry.
• Member Port
Display the current member port.
• Modify
Click to edit or delete the SVLAN ID.
4.5.5.3 SVLAN PVID Settings
The SVLAN PVID Settings screen in Figure 4-5-9 & Figure 4-5-10 appears.
Figure 4-5-9 SVLAN PVID Setting page screenshot
The page includes the following fields:
Object Description
• Port
Select port number for this drop down list to assign TPID.
• PVID
Allow assign PVID for selected port. The range for the PVID is 1-4094.
Buttons
: Click to apply changes.
