User’s Manual of WGSW-28040 / 28040P
138
The page includes the following fields:
Object Description
• Priority
Display the current priority.
• Queue ID (1-8)
Display the current queue ID.
4.8.6 Packet Scheduling
This page provides Packet Scheduling. The Packet Scheduling screen in Figure 4-8-9 & Figure 4-8-10 appears.
Figure 4-8-9 Per Port Setting page screenshot
The page includes the following fields:
Object Description
• Port
Select port for this drop down list.
• Schedule Algorithm
Select schedule algorithm mode.
Buttons
: Click to apply changes.
