User’s Manual of WGSW-28040 / 28040P
76
The page includes the following fields:
Object Description
• Protected Type
Display the current protected type.
• Port List
Display the current port list.
4.3.8 Bandwidth Control
Configure the switch port rate limit for the switch port on this page. The settings relate to the currently selected stack unit, as
reflected by the page header.
4.3.8.1 Preamble Setting
This page provides to select the ingress and egress preamble. The Bandwidth Control Peramble Setting screen in Figure 4-3-15
& Figure 4-3-16 appears.
Figure 4-3-15 Bandwidth Control Peramble Setting page screenshot
Buttons
: Click to apply changes.
The page includes the following fields:
Object Description
• Ingress Preamble &
IFG
Select Ingress preamble & IFG mode.
• Egress Preamble & IFG
Select egress preamble & IFG mode.
