User
’s M
anual of WGSW
-28040 / 28040P
144
Figure 4-8-16
Queue
Remarking T
able S
tatus page screenshot
The page
includes the fol
lowing field
s:
Object
Description
•
Priority
Display the current priority
.
•
New 802.1p
Priority
(0-7)
Display the current new 802.1p priority
.
•
New DSCP V
alue (0-63)
Display the
current new
DSCP
value.
143
145
