User’s Manual of WGSW-28040 / 28040P
65
• Tx Bad Packets
The number of frames transmitted in error and the number of incomplete
transmissions per port.
• Rx Good Packets
The number of received good packets per port.
• Rx Bad Packets
The number of frames received in error and the number of incomplete
transmissions per port.
Buttons
: Clears the counters for all ports.
: Click to refresh the page immediately.
Figure 4-3-4 Trunk Statistic page screenshot
The displayed counters are:
Object Description
• Trunk
This is the number for trunk entry.
• Tx Good Packets
The number of transmitted good packets per trunk.
• Tx Bad Packets
The number of frames transmitted in error and the number of incomplete
transmissions per trunk.
• Rx Good Packets
The number of received good packets per trunk.
• Rx Bad Packets
The number of frames received in error and the number of incomplete
transmissions per trunk.
