The page includes the following fields:
Object Description
• Trunk
Select trunk number for this drop down list.
• Type
Indicates the trunk type. This field is only valid for stackable switches.
Static: Force aggregared selected ports to be a trunk group.
LACP: LACP LAG negotiate Aggregated Port links with other LACP ports located
on a different device. If the other device ports are also LACP ports, the devices
establish a LAG between them.
• Ports
Select port number for this drop down list to esatablish Link Aggregation.
• LACP Active
Indicates the LACP activity status. The Active will transmit LACP packets each
second; while Passive will wait for a LACP packet from a partner (speak if spoken
to).
Buttons
: Click to apply changes.
Figure 4-4-3 Trunk Group Information page screenshot
The page includes the following fields:
Object Description
• Trunk
Display the current trunk entry.
• Type
Display the current trunk type.
• Master Port
Display the current master port.
• Member
Display the current member of link aggregation.
• Active/Passive
Display the current trunk role.
• Aggregated
Display the current aggregated status.
• Delete
Click to delete the trunk group entry.
