Chapter C - SERVICE MODE
Planmeca Compact i C-13
GENERAL ABOUT THE SERVICE MODE
Technical Manual
n.109 Unit type setting to enable or disable the IMUX and the
door features
0 = Compact i
1 = Compact e
28 = Cart
31 = Independent Cart
44 = no Instrument Console
C-40
n 110 Show IC39 outputs For factory use C-40
n 111 Show inputs IN3 (IC39) For factory use C-41
n 112 Show inputs IN4 For factory use C-41
n 113 Show side delivery arm emergency switches signals ---- = no side delivery arm
DxUy; x = downwards switch
y = upwards switch
0 = switch not activated
1 = switch activated
C-41
n 114 Show bowl position 0 = bowl not in rest position
1 = bowl in rest position
C-41
n 115 Show glass identification signal 0 = glass is not in holder
1 = glass is in holder
C-41
n.116 Select glass filling mode 0 = no identification
1 = glass identification activated
(default)
2 = automatic glass filling
C-41
n 117 Show active time of drive air pulse width modulation For factory use C-41
n 118 Show active time of spray water pulse width modulation For factory use C-41
n 119 Show active time of spray air pulse width modulation For factory use C-41
n 120 Show active instrument power consumption nn W C-42
n.121 Select the length of the automatic legrest 0 = 510 (default)
1 = 460
2 = 390
C-42
n.122 Armrest selection 0 = armrests deselected
1 = armrests selected (default)
C-42
n.123 Factory test - C-42
n.124 Set the type of Planmeca Compact i 0, 1 C-42
n 125 Show Water management system status nnn C-42
n 126 Show Water management system inputs and outputs ¦¦¦¦¦¦¦¦ C-43
n.127 Water management system water flow adjustment C-43
n.128 Fake pressure sensor readings 0 = normal
1 = fake pressure readings
n.129 Adjustment of the upper limit of pre-programmed chair
positions
C-43
n.130 Disable WCS 0 = WCS in use (default)
1 = Starting of WCS disabled
2 = WCS totally disabled
C-43
n.131 WCS: adjustment of the syring cleaning solution filling
time
20 - 180, (default = 40) C-44
Table 11: Other service modes
MODE SERVICE MODE FUNCTION DISPLAY/RANGE page
