Application > VGL Setup > Expanded Font
Expanded font allows you to print characters in different sizes with specified
parameters and allows you to select block or non-block font face.
Uses Gothic font as default. Other font faces can be
selected by using the IFONT command.
Application > VGL Setup > Auto FF at ^PN
When enabled, an FF will be generated automatically to slew to the end of
form when the ^PN command is encountered and when the current vertical
position is not at the top-of-form.
No FF generated upon ^PN command.
FF is generated upon ^PN command.
Application > VGL Setup > PDF Size Comp
This option is for compatibility of the font size of the barcode printable data
field (PDF) on older firmware.
Uses the normal font size.
Matches the older firmware font size.
Application > VGL Setup > C128 Mode Comp.
This option is for compatibility with mode switches for Code 128 barcodes.
Uses the normal auto switch for optimum barcodes.
Matches the older firmware auto switch algorithm.
