Printronix T6000 - Page 27

27
6. The ribbon and media loading illustration label (shown below) is located on the inside of the media
covers of all 4 inch and 6 inch width T6000 model printers.
Media Hanger
Guide
Media Damper Guide
(RFID Models)
Media Damper
Guide Locking Knob
(RFID Models)
Media Guide
Media Sensor
Assembly
