Media > Image > Set Label Length
This feature selects whether the Sensed Distance value derived from an Auto
or Manual Calibrate will be used to set the Label Length menu. If no calibration
is performed, this menu has no effect.
The Sensed Distance will not override or change the
Label Length value.
The Sensed Distance value will override and change
the Label Length value. If Sensors Control > Gap/Mark
Sensor = Gap, the printer will subtract the Sensors >
Calibrate > Gap Length value.
For Automatic setting, the Sensors > Calibrate >
Use Label Length is ignored (treated as disabled).
Media > Image > Clip Page
This option determines how the printer handles images that are too large for
one physical page length when using gap or black mark media.
When the user-selected page length (logical length) is
greater than the physical page length dictated by the
gap, notch, hole, or black mark on media, the printer
continues to print the remaining excess data onto the
next physical page.
The printer clips any excess data to fit the physical
page. The excess data is lost. The media sensor
constantly looks for the gap, notch, hole, or black mark
and when detected, uses it as the TOF position for the
next label and clips any remaining data.
See Intro: Clip Page 53 for more explanation when
this menu option is disabled.
Media > Image > Vertical Shift
This option specifies the amount to shift an image vertically up (-) or down (+)
for precise positioning on the label. The actual height of the image is not
affected by this parameter. The adjustment is made in .01 inch increments.
Label Length (max 12.80 inches)
