Media > Image > Horizontal Shift
This option specifies the amount to shift an image horizontally left (-) or right
(+) for precise positioning on the label. The actual width of the image is not
affected by this parameter. The adjustment is made in .01 inch increments.
Media > Image > Orientation
This menu item selects the image orientation to be used when printing the
label. See picture below for an illustration. Not available for the
Postscript/PDF firmware.
Portrait refers to vertical page orientation, where the top
of the page is at the leading edge.
Landscape is a rotation of the logical page at 90
degrees clockwise from Portrait.
Inverse Portrait is a rotation of the logical page at 180
degrees from Portrait.
Inverse Landscape is a rotation of the logical page at
270 degrees clockwise from Portrait.
The orientations shown here are with Print
Direction set to Head First. Some IGP Emulations
such as ZGL use Foot First. In that case, the
orientations would be 180 degrees different for all
selections shown here.
