Quantum Scalar i80 User Manual

Chapter 8: Getting Information About the Library
Viewing the Location of the Robot
208 Quantum Scalar i40 and Scalar i80 User’s Guide
Note: The operator panel does not update the left side graphical
display until the motion is complete (success or failed)
On the operator panel, do the following:
Note: If you are viewing the alternate home screen, select Menu to
return to default home screen.
1 Select Tools > Robotic View.
The left graphical section depicts the top-down current location of
the robot on the X axis.
• The numbers indicate the storage column.
• The 'D' designates the tape drive column.

Quantum Scalar i80 Specifications

General

Power supply type	AC
Power requirements	100 – 240V, 50/60Hz
Power consumption (typical)	200 W
Dimensions (WxDxH)	445 x 793 x 264 mm
Media types supported	2x LTO-4
Maximum supported storage capacity	128 TB
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Form factor	6U
Product type	Storage auto loader & library
Certification	IEC 60950, Class A / FCC part 15, ICES-003, CISPR 22, EN55022 Class A, VCCI, CNS 13438, KN22, AS/NZS CISPR 22, EN61000-3-2, EN61000-3-3 EN55024, KN24 CE, VCCI, GS, FCC, ICES, NRTL, GOST, BSMI, KCC
Product color	Black
Standard interfaces	Fiber Channel

Weight and Dimensions

Weight	23800 g
