ABL800 FLEX Operator's Manual 2. What Is what
Screen elements, Continued
Center section
(continued)
Screen keyboard is used for entering both alphabetical and numerical data − see
the description on the next page.
ctivated text box
The keyboard functions as a normal keyboard with alphabetical and numerical
characters. The typed text appears in the activated text box.
Enter
Press to confirm the entry and to return to the previous screen.
Backspace
Press to delete characters from right to left.
Press to cancel any changes made in the activated text box and
to return to the previous screen
Press to delete an entry in the activated text box.
Shift
Press to type a capital letter or symbol.
Press to lock the keyboard in order to type capital letters and
symbols on the numerical keys. When activated, indicator is
green.
Up/down/left/right arrows move the cursor in the activated text
box in order to edit a text.
Continued on next page
2-21
