Auxiliary Software
CS210 Rev. B4 Feb 2015 103
Figure 97: Pyrometer screen
11.3.1.3 Digital Output
If the selected device is <Digital Output> and its options have been correctly configured, the system
will open the port. Next step will be selecting the interval of the output module addresses connected
to the PC, and then, click on the green arrow. If the connection goes thru, the connected digital output
modules as well as their features will show in the screen.
If, on the other hand, any of the options has not been properly entered, or if the connection with any of
the devices did not go thru, an error message will be displayed.
Figure 98: Digital Output screen
