Technical Data
CS210 Rev. B4 Feb 2015 9
2. Technical Data
2.1 Specifications
Linescanner
Type MP150HR linescanner
Temperature range: 100 to 650°C (212 to 1202°F)
Optical resolution (90% energy) 170 : 1 (IFOV = 5,9 mrad)
1
Spot detection (50% energy) 510 : 1 (IFOV = 2,0 mrad)
2
Spectral response: 3.5 to 4 µm
Scan angle (FOV): 90°
Accuracy: ± 0.5% of reading or ± 3°C (± 6°F)
whichever is greater,
at 0 - 50°C (32 - 122°F) ambient temperature for the scanner
Repeatability: ± 1°C (± 2°F),
at 0 - 50°C (32 - 122°F) ambient temperature for the scanner
Detector: HgCdTe
Sampling rate: 1024 pixel per scan line
Standard focal distance: infinity
Mechanical scanning system: MTBF: 40,000 hours
Power requirement: 100 to 240 VAC (for the system connection box in the field)
Protection rate: IP65 (NEMA4) protection for linescanner
Ambient temperature range:
(for scanner with housing)
- without cooling: -40 to 45°C (-40 to 113°F), no direct sunlight
Warm-up time: 20 minutes
System
Scan lines: 200
Min. kiln speed: 0.02 rpm (for synchronized measurement)
Max. kiln speed: 6 rpm @ 200 lines @ 20 Hz scan speed
(for synchronized measurement)
Packaging: CS211: about 40 kg (88 lb)
CS212: about 80 kg (176 lb)
2.2 Scope of Delivery
The standard CS211 package includes:
Scanner: Linescanner MP150HR
(CS212: 2 units, CS213: 3 units, CS214: 4 units)
7.5 m (24.6 ft) Ethernet cable
7.5 m (24.6 ft) power cable
1
at 20 Hz scan speed
2
at 20 Hz scan speed
