Technical Data
CS210 Rev. B4 Feb 2015 11
Protective Housing: Length: 452 mm (17.79 in)
(with mounting bracket Width: 496 mm (19.53 in
and protective sighting channel) Height: 450 mm (17.72 in)
Weight: 13 kg (28.6 lbs)
Position indicator:
Sensor head: Length: 50 mm (1.97 in)
Diameter: 50 mm (M50 x 1,5) (1.97 in)
Weight: 0.3 kg (0.66 lbs)
Junction box: Length: 84 mm (3.31 in)
Length: 110 mm (4.33 in) with electronic tube
Width: 79 mm (3.11 in)
Height: 67 mm (2.64 in)
Weight: 0.7 kg (1.5 lbs)
System Connection Box: Width: 380 mm (15 in)
Height: 380 mm (15 in)
Deep: 210 mm (8.3 in)
Weight: 9.8 kg (22 lb) - netto
