Configuration
CS210 Rev. B4 Feb 2015 31
The CS software provides the following data via OPC connections. All items listed below have read-only
access.
Item
Type
Description
Synchronization
.System is synchronized
Bool
Flag for indicating that the system runs synchronized to the oven
Graphic
.Maximum temperatures
Integer array
Provides the Maximum Temperature Profile (temperature via pixel number)
.Minimum temperatures
Integer array
Provides the Minimum Temperature Profile (temperature via pixel number)
.Average temperatures
Integer array
Provides the Average Temperature Profile (temperature via pixel number)
Live Ring Migration system
.Rings
Integer
Number of rings currently used for Live Ring Migration
.Ring 1.Time
Integer
Revolution time for ring 1
.Ring 1.Offset
Integer
Offset time for ring 1 compared to kiln revolution time
.Ring 1.State
Bool
Status for ring 1
Alarm zones
.Zone 1.Maximum temperature limit
Integer
Upper alarm threshold for zone 1
.Zone 1.Hysteresis (low)
Integer
Hysteresis for zone 1 (reset threshold for an alarm)
.Zone 1.Maximum temperature
Integer
Maximum temperature for zone 1
.Zone 1.Alarm State
Bool
Alarm status for zone 1
Devices
.Kiln.Rotation velocity
Integer
Rotation velocity for the kiln given in rpm
.Kiln.Lap time
Integer
Rotation time for the kiln
.Kiln.Snapshot Counter
Integer
Snapshot counter, will be increased by 1 with each new stored image into the database, can be
used as live counter
.Kiln.Points of reading
Integer array
Provides the Length Profile of the kiln (location of each pixel)
.Scanner 1.State
Bool
Status for scanner 1
.Scanner 1.Internal temperature
Integer
Internal temperature for scanner 1
.Pyrometer 1.State
Bool
Status for pyrometer 1
.Pyrometer 1.Internal temperature
Integer
Internal temperature for pyrometer 1
.Pyrometer 1.Maximum temperature
Integer
Maximum temperature for pyrometer 1
.Pyrometer 1.Dirty lens alarm limit
Integer
Threshold for dirty lens alarm for pyrometer 1 (shadow pyrometer only)
.Pyrometer 1.Dirty lens alarm state
Bool
Dirty lens alarm status for pyrometer 1 (shadow pyrometer only)
.Pyrometer 1.Type
String
Pyrometer used for: <burningZone> or <shadowPyrometer>
.Pyrometer 2.Burning zone
Integer
Temperature of the burning zone for pyrometer 2 (burning zone pyrometer only)
