Accessories
CS210 Rev. B4 Feb 2015 93
Wiring:
For detailed wiring of Burning Zone Monitoring see section 13.10 Burning Zone Wiring, page 126.
For recommended cables see section 4.5 Cable Requirements, page 14.
Technical data:
MR temperature range 700 to 1800°C (1292 to 3372°F)
Spectral response 1 µm nominal
Accuracy ± (0.5% T
measured + 2°C), Tmeasured in °C
Optical resolution 82 : 1 (95% energy)
Protection rate (sensor) IP65 (NEMA-4)
Ambient temperature
without cooling 0 to 50°C (32 to 122°F)
with ThermoJacket up to 315°C (600°F)
Cable length 15 m (49 ft.)
Digital interface RS485
For other technical data see MR operators manual and the ThermoJacket operators manual.
