OTHER REPLACEMENTS
B039/B040/B043 3-44 SM
3.12 OTHER REPLACEMENTS
3.12.1 QUENCHING LAMP
1. PCU (☛ 3.6.1)
2. Quenching lamp [A] (" x 1)
3.12.2 HIGH-VOLTAGE POWER SUPPLY BOARD
1. Rear cover (☛ 3.3.1)
2. High-voltage power supply board [B] (!
x 3, 2 standoffs, all connectors)
B039R921.WMF
B039R959.WMF
[A]
[B]
