Ricoh B039 - Overall Information; Mechanical Component Layout

Document
Feeder
B387
MECHANICAL COMPONENT LAYOUT
SM 8-1 B387
1. OVERALL INFORMATION
1.1 MECHANICAL COMPONENT LAYOUT
1. Separation roller
2. Original feed belt
3. Pick-up roller
4. Original entrance guide
5. Original table
6. Original exit roller
7. 2nd transport roller
8. Original exposure guide
9. 1st transport roller
B387V103.WMF
1
2
67
8
9
3
4
5
