DRAM INSTALLATION

B039/B040/B043 1-20 SM

1.9 DRAM INSTALLATION

NOTE: The IMB must be installed before installing the DRAM.

1. Remove the rear middle cover [A] (2 rivets).

2. Install the DRAM [B].

3. Reinstall the rear middle cover.

B039I934.WMF

B039R942.WMF

[A]

[B]
