Fax Unit B404
BIT SWITCHES
SM 5-33 B404
Communication Switch 01
No FUNCTION COMMENTS
6
7
Maximum printable page length
available
Bit 7 6 Setting
0 0 No limit
0 1 B4 (364 mm)
1 0 A4 (297 mm)
1 1 A3 (432 mm)
The setting determined by these bits is informed to
the transmitting terminal in the pre-message
protocol exchange (in the DIS/NSF frames).
Communication Switch 02
No FUNCTION COMMENTS
0
Burst error threshold
0: Low 1: High
If there are more consecutive error lines in the
received page than the threshold, the machine will
send a negative response.
The Low and High threshold values depend on the
sub-scan resolution, and are as follows.
Resolution 100 dpi 200 dpi 400 dpi
3.85 l/mm 7.7 l/mm 15.4 l/mm
Low settings 6 12 24
High settings 12 24 48
1 Acceptable total error line ratio
0: 5% 1: 10%
If the error line ratio for a page exceeds the
acceptable ratio, RTN will be sent to the other end.
2
Treatment of pages received
with errors during G3 reception
0: Deleted from memory
without printing
1: Printed
0: Pages received with errors are not printed.
3 Hang-up decision when a
negative code (RTN or PIN) is
received during G3 immediate
transmission
0: No hang-up, 1: Hang-up
0: The next page will be sent even if RTN or PIN is
received.
1: The machine will send DCN and hang up if it
receives RTN or PIN.
This bit is ignored for memory transmissions or if
ECM is being used.
4-5 Mistaken Auto Service Call
prevention
Bit 3 Bit 2 Setting
0 0 None
0 1 8 digit CSI
1 0 4 digit CSI
1 1 CSI/RTI
(0,1) - The machine will disconnect the line without
sending a fax message if the last 8 digits of the
received CSI do not match the last 8 digits of the
dialed telephone number. This does not work when
manually dialed.
(1,0) - The same as above, except that only the last
4 digits are compared.
(1,1) - The machine will disconnect the line without
sending a fax message, if the other end does not
identify itself with an RTI or CSI.
(0,0) - Nothing is checked; transmission will always
go ahead.
6-7 Not used Do not change the settings.
