Fax Unit B404
SERVICE RAM ADDRESSES
SM 5-67 B404
6803AB to 6803AD(H) - Effective term of automatic service calls
Parameters Address (H)
Year: last two digits of the year (BCD) 6803AB
Month: 01 through 12 (BCD) 6803AC
Day: 01 through 31 (BCD) 6803AD
680400 to 6804E0(H) - NCU parameters (Refer to section 4.3 for details)
680CC8 to 680CEF(H) - SC codes NOT for automatic service call
If the fax unit receives a copier engine SC code other than those programmed in
these addresses, the fax unit sends an automatic service call report to the
programmed service station.
Six SC codes have already been programmed at default, as shown in the table
below. Fourteen more SC codes can be programmed, if required (if an address
contains FF(H), a code is not programmed in it).
Program a SC code in four-digit BCD format as shown in the example below.
Example 1: SC code ‘192’
Address (High) - 01 (BCD)
Address (Low) - 92 (BCD)
Wildcard characters “a” or “A” can be used to specify a series of SC codes.
Example 2: SC code ‘900 to 999”
Address (High) – 09 (BCD)
Address (Low) – aa or AA (Hex)
Example 3: SC code ‘330 to 339”
Address (High) – 03 (BCD)
Address (Low) – 3a or 3A (Hex)
- Default settings -
High Address (H) Data (BCD) Low Address (L) Data (BCD) SC code
680DC8 01 680DC9 92 192
680DCA 09 680DCB 80 980
680DCC 09 680DCD 99 999
680DCE
to
680DEE
FF(H)
680DCF
to
680DEF
FF(H) Not Programmed
687BCC to 687FCB(H) - Dedicated tx parameters for Quick Dial 01 - 32.
There are 32 bytes for each Quick Dial. Only the 23rd to 32nd bytes are used.
6884B2 to 6884BB(H) - Dedicated tx parameters for Quick 01
6884D2 to 6884DB(H) - Dedicated tx parameters for Quick 02
6884F2 to 6884FB(H) - Dedicated tx parameters for Quick 03
"
688892 to 68889B(H) - Dedicated tx parameters for Quick 32
