Ricoh P C301W - Fusing Motor (M4)

4.Replacement and Adjustment
88
2. Remove the paper transport motor (M3) [A].
Fusing Motor (M4)
1. Remove the left cover. (Left Cover)
2. Disconnect the fusing connector [A].
3. Release two hooks to remove the fusing relay connector [A].
