4.Replacement and Adjustment
121
13. Remove the ID chip board (PCB6) [A].
PSU (PCB4)
• Turn off the main power switch and unplug the power cord before replacing the PSU.
• To avoid electric shock from residual charge on the board, never touch the areas outlined in
red [A] in the following diagrams when replacing the PSU.
100V model:
200V model:
1. Remove the rear cover. (Rear Cover)
2. Remove the left cover. (Left Cover)
To Next Page
