Ricoh P C301W - ITB Contact Motor (M6)

4.Replacement and Adjustment
65
4. Remove the motor bracket [A]. ( × 2)
5. Remove the waste toner collection motor assembly [A]. ( × 1, × 1)
6. Remove the waste toner collection motor (M7) [C]. ( × 2)
ITB Contact Motor (M6)
1. Remove the rear cover. (Rear Cover)
