Ricoh P C301W - Waste Toner Bottle Set Sensor (S10)

4.Replacement and Adjustment
71
8. Remove the waste toner overflow sensor (S9) [A]. ( × 1)
Waste Toner Bottle Set Sensor (S10)
1. Remove all AIO cartridges. (AIO Cartridge)
2. Pull out the image transfer belt unit a little. (Image Transfer Belt Unit)
3. Remove the rear cover. (Rear Cover)
4. Remove the controller box cover [A].
Printer model:
MF model:
5. Remove the AC detection board with the harness guide. (AC Detection Board (PCB5))
